EasyMikz-50
High-performance metering and mixing machine for larger-scale production.
Overview
The EasyMikz-50 uses independent inverter driven motors for each gear pump, ensuring greater efficiency and precise mixing ratios. Its portable frame allows for mounting larger material reservoirs or tanks. While mostly used for manual applications, it can also be interfaced to fully or semi-automatic systems.
Materials Processed:
PolyurethaneEpoxyResinSilicone
Technical Specifications
| Specification | Value |
|---|---|
| Mixing Ratio | 1:1 to 100:1 (depending on pump capacity) |
| Viscosity | Up to 30,000 mPas |
| Flow Rate | Up to 2500 ml/min |
| Mixing Type | Static or Dynamic system |
| Tank Capacity | Upto 100 liters stainless steel |
| Temperature | 100 degree Celsius |
| Electric Supply | 230-415 V / 50Hz |
| Compressed Air | 6 bar |
Benefits
- Higher flow rates are possible on request.
- Can be used for a different applications.
- Accurate flow-rate control.
- Uniform flow.
- Pulse less dispensing.
- Variable mixing ratio.
- Easy operation.
Typical Applications
- Electronic Potting
- Component Bonding and sealing
- Filter Manufacturing
- Casting
- Moulding
Standard Features
- Metering Pumps: Gear pumps with geared motor and inverter controls.
- Mixing Gun: Pneumatically operated.
- Calibration: User free mixing ration calibration.
- Service indicator LED.
- Controls: Integrated PLC control with HMI touch screen and variable ratio adjustment.
- Air supply filter/regulator and gauge with connection check unit.
- Either foot pedal, hand held trigger or remote start options available.
Options
- Tank sizes up to 100 Its capacity.
- Digitally controlled heating to Tank, pumps and hoses.
- Electric agitation to material Tanks.
- Electronic low-level sensing to material tanks alarms.
- Stainless steel wetted parts to protect against corrosion.
- Hardened parts to protect against abrasion.
- Ultra-high precision Gear Metering Pumps.
- Vacuum degassing to material tanks.
- Static disposable mixing option.
- Dynamic mixing head (electrically driven) for high flow applications.
- Bulk feed transfer pump/accumulator facility directly from suppliers containers.
